Quick Vision Hyper UMAP

The UMAP measuring system uses an ultra-low force probe along with Mitutoyo proprietary sensing technology to attain highly accurate measurements on micron scale features.

Download Brochure
Features & Benefits

The Mitutoyo Quick Vision Hyper UMAP features an ultrasonic micro probe that senses the amplitude variation while probing. The extremely small stylus, with high aspect ratios, makes dimensional measurements of microscopic forms possible, and can measure form deviations of features too small for traditional probe technology.

  • Camera and UMAP probe provide high-accuracy contact and non-contact measurements in one machine
  • Several diameters of micro-stylus are available from 15 µm to 300μm diameter
  • Programmable turreted zoom changes the magnification multiplier from 1X to 6X
  • A Programmable Ring Light (PRL) allows for fine control and direction for optimal measurement illumination to enhance the edge of inclined surfaces and very small steps
  • Main frame structure has a fixed-bridge construction achieving high-accuracy measurements
  • Standard temperature compensation offers higher accuracy in measurements
  • The accuracy of this model conforms to ISO10360-7:2011 (specifications on request)
SERIES 364 TECHNICAL DATA
Technology: CNC VMM
Scale Resolution: 0.0000007874" / 0.00002mm
Environment: 68°F
20°C
Camera Type: B&W CCD
Field of View: 0.0016 x 0.0012 - 0.4937 x 0.3701" / 0.04 x 0.03 - 12.54 x 9.4mm
Zoom Type: Internal Turret
Magnification: 16x - 4800x
Illumination System: -
Required Air Pressure: 0.5 Mpa - 0.9 Mpa
Touch Trigger Probe: No
Color Lighting: Special order
Optical 3D Scanning (PFF): Optional
Laser Tracking Autofocus (TAF): Special order
Vibration Stand: Optional
PRODUCT LIST
Order No.: Model: Range X-Axis: Range Y-Axis: Range Z-Axis: Workpiece Max Load: Mass (incl. stand and controller): Dimensions:
364-713-20S UVS2-H302P1L-D (Hyper Umap 302) 12" / 300mm 8" / 200mm 8" / 200mm 33lbs / 15kg 816lbs / 370kgs 37 x 34 x 63" (951 x 859 x 1609mm)
